New Slot Box for Quads?
Goto page 1, 2  Next

Post new topic   Reply to topic    iWindsurf Community Forum Index -> Southwest USA, Hawaii, Mexico
View previous topic :: View next topic
Author Message
Waterat Pat



Joined: 10 Apr 2000
Posts: 172

PostPosted: Sun Jun 05, 2011 9:49 am    Post subject: New Slot Box for Quads? Reply with quote

Been a tough season this year as I have already broken 2 boards. so I have been researching the latest and greatest Quad boards. I came across a new finbox called the Slotbox which claims to be far lighter. Here is the link to check it out.

http://www.tabou-boards.com/images/downloads/2011/pdf/2011t-slotbox-launchpaper-0.1lr.pdf

Anywho I have been trying to find the manufacturers that actually uses it. Tabou doesn't even make a quad. It appears Starboard is going to use it but I am not wild about there Quad offering. Anyone know if Quatro is going to switch over?
Back to top
View user's profile Send private message
Kevinmc



Joined: 05 May 1998
Posts: 77

PostPosted: Sun Jun 05, 2011 11:18 am    Post subject: Reply with quote

Quote:
Tabou doesn't even make a quad.


Hmmm... Are you saying I've been riding counterfeit Tabou quads all year?!?!? Shocked
Back to top
View user's profile Send private message
loopless



Joined: 30 Jun 1997
Posts: 382

PostPosted: Sun Jun 05, 2011 4:07 pm    Post subject: Reply with quote

What a good idea.. I hope the other board makers adopt it. The US fin box is well past it's use by date... a hold over from the days of the one-design with a teak boom and rope in-haul.
Back to top
View user's profile Send private message
kevinkan



Joined: 07 Jun 2001
Posts: 1556
Location: San Francisco

PostPosted: Mon Jun 06, 2011 12:44 am    Post subject: Reply with quote

I read somewhere (I don't remember where) that slot boxes aren't really any lighther than similar length US boxes. That said, I can't stand the dumb fin tab and screw arrangement w/ US boxes, and slot boxes look a lot more user friendly and would gladly welcome a change if they are as functional as the US box. I did see a board w/ a slot box where the screw heads stood proud of the surface of the board which seemed kind of odd... probably something easily fixable, but kind of weird to see on a production board.
_________________
Kevin Kan
Sunset Sailboards, San Francisco CA
http://www.sunsetsailboards.com
https://www.instagram.com/sunsetsailboards
http://www.facebook.com/sunsetsailboards
Back to top
View user's profile Send private message Visit poster's website
rich1



Joined: 10 Apr 2000
Posts: 156

PostPosted: Tue Jun 07, 2011 12:26 pm    Post subject: Reply with quote

I like this a lot. I've been putting tuttle boxes on my boards (I shape my own) because of all the drawbacks of the old box. I was about to start prototyping a box the works in a similar way (I now make my own boxes from scratch out of CF) I was buying US box fins and installing the tuttle adapter. This got me thinking about a US box with one side cut on an angle. A wedge would then screw in and clamp the fin. Now that I see this, it is pretty much the same thing, with no wedge. Simple is better! I also really love that he went open source rather than the patent route. This really should be the end of the US box.

I'm not sure about the weight savings though. Once you make them strong enough for a single fin, they should be the same as a regular US box.

Chris
Back to top
View user's profile Send private message
U2U2U2



Joined: 06 Jul 2001
Posts: 5043
Location: Shipsterns Bluff, Tasmania. Colorado

PostPosted: Tue Jun 07, 2011 8:59 pm    Post subject: Reply with quote

Slot Boxes were developed by Tabou, then Starboard came on, AFAIK they are make in the Cobra factory, no where else.

They come in 2 lengths, 13cm and I believe shorter, they are installed on the Tabou quads and Pocket Wave as the side fins.

Tabou, Starboard, RRD and Simmer are all using them, they are MUCH lighter than anything else.

the fins are held in by 2 screws on the side, this system seems pretty strong to me, for fins around 16cm and down , little effort to seat screws flush.

the other major board makers would/HAVE had the oppurtunity to use the slotbox, it has no patent, and can be made by anyone.

its attraction now is . light weight, especiall for 4 boxes, you can use slotbox fins OR US Box fins by removing the pin and cutting off the forward tab, and some indent/dimples for the screws to set in.

mine should be here this week from Cobra.

_________________
K4 fins
4Boards....May the fours be with you

http://www.k4fins.com/fins.html
http://4boards.co.uk/
Back to top
View user's profile Send private message
bradj



Joined: 05 Jun 2005
Posts: 48

PostPosted: Tue Jun 07, 2011 10:38 pm    Post subject: Reply with quote

consider replacing the Phillips screws with stainless steal socket head (hex) screws, more reliable engagement with the tool
Back to top
View user's profile Send private message
rich1



Joined: 10 Apr 2000
Posts: 156

PostPosted: Wed Jun 08, 2011 8:31 am    Post subject: Reply with quote

Quote:
mine should be here this week from Cobra


Could you post some pics? I've only seen drawings of the thing. The drawings suggest it's all made out of CF

Chris
Back to top
View user's profile Send private message
U2U2U2



Joined: 06 Jul 2001
Posts: 5043
Location: Shipsterns Bluff, Tasmania. Colorado

PostPosted: Wed Jun 08, 2011 10:11 am    Post subject: Reply with quote

I will post photos

this has one of the better details that I have seen, 1 quik glance at the box.



http://www.star-board.com/2010/news_events/read.php?threadid=9229

when these 1st came out I was somewhat heistant to believe all the details, Simmer will have their own board line later on this year and is using the slotbox, little more convincing on the details.

it is somewhat similar to the installation process I use for ProBox on my garage conversion, haveing just removed 4, and tested before they are pretty strong when installed with some support structor and fiberglass overlay.

http://www.proboxhawaii.com/pages/products/products_boxes.html

_________________
K4 fins
4Boards....May the fours be with you

http://www.k4fins.com/fins.html
http://4boards.co.uk/
Back to top
View user's profile Send private message
U2U2U2



Joined: 06 Jul 2001
Posts: 5043
Location: Shipsterns Bluff, Tasmania. Colorado

PostPosted: Wed Jun 08, 2011 7:08 pm    Post subject: Reply with quote

top is 10cm bottom is 13cm



the cassettes are the same size, 10 or 13cm box, the length is really long, will need to be cut to fit.



the fin is a slotbox base K4 from England, fits like a glove



_________________
K4 fins
4Boards....May the fours be with you

http://www.k4fins.com/fins.html
http://4boards.co.uk/
Back to top
View user's profile Send private message
